Touch Current
The following touch current test points are defined for the EM Tracking Unit in combination with
the Monitor Cart.
Measurement Point
Power connector at combined power and data cable
(for optional EM Tracking Unit)
EM Field Generator at EM Base Station
(for optional EM Tracking Unit)
Power connector at EM Base Station
(for optional EM Tracking Unit)
Mounting suspension at EM Base Station
(for optional EM Tracking Unit)
EM instrument port at EM Base Station (type BF applied
part SIP/SOP)
(for optional EM Tracking Unit)
Housing screw on EM Base Station cover
(for optional EM Tracking Unit)
Tracking system connection on Monitor Cart
(for optional EM Tracking Unit)
ELECTRICAL SAFETY
