10.2.2 LEDs and indications
The LED lamps on the front panel indicate the status of the equipment. The straight/dashed lines
indicate if the lamps are lit continuously/flashing.
The LED lamps on the front panel indicate the status of the equipment. The straight/dashed lines
indicate if the lamps are lit continuously/flashing.
(green)
ACTIVE
POWER
Bilgmon488 is in ACTIVE mode (separator is running).
BilgMon488 is in POWER mode (menu subsystem is active).
(red)
ALARM
(no signal)
No alarm2 present.
Alarm2.
(yellow)
VALVE
OPEN
(no signal)
Automatic stopping device activated (back to bilge tank).
Automatic stopping device NOT activated (overboard valve open).
