110
ADJUSTING WHEEL TREAD
When changing tires, please use a hoist or
strong support and make sure the tractor
does not move.
[Otherwise]
There is a risk of death or injury.
WARNING
Adjust the wheel tread depending on the type and con-
dition of the work. Also, increase the wheel tread when
working on a slope or towing.
a) Pull the parking brake, block the front wheels, and
raise the body with a jack to make the rear wheel lift
from the ground.
b) To make sure adjustments alternatively between the
left and right wheel.
<FRONT / REAR WHEEL>
DESCRIPTION TIGHTENING TORQUE
Bolts on wheels and axle 280 lbf-ft
(40 kgf.m)
Bolts on rim and disk of
wheels
250 lbf-ft
(35 kgf.m)
