144
10. AIR COMPRESSOR BELT
Carry out inspection or maintenance after the
engine if fully cooled down.
[Otherwise]
There is a risk of getting burnt.
CAUTION
Check if belt is sagging for about 0.39~0.6in [10~15mm]
or check for any damage to the belt by opening bonnet
and engine side cover and pressing the middle of fan
belt.
When it is not sagging enough, adjust tension by using
adjusting bolt at the front of compressor.
Change the belt when tension cannot be adjusted even
when the bolt is tightened as much as possible.
PERIODIC MAINTENANCE & ADJUSTMENT
