75
5. REAR REMOTE CONTROL LEVER
It is used to for the rear implement hyd-function.
LEVER# I II III
DETENT N/A FRONT/REAR N/A
Hitch control lever can freely lift up or move down the
rear implement. It will lift up when lever is pulled back
and move down when lever is pushed forward.
One-touch lifting up/down switch can lift up to the preset
point set by upper limit control dial and move down to
position of control lever.
6. 3PT HITCH CONTROL LEVER
(Electric over hydraulic control)
To avoid personal injury, do not use one-
touch switch when engaging or disengaging
the implement
WARNING
FUNCTIONS
