142
[How to remove air]
1) Start engine and set revolution at 1500 rpm.
2) Insert tube in air removal pipe in rear upper part of the
transmission and put the part opposite of tube into mis-
sion oil intake.
3) Release air removal valve opening bolt.
4) Pump brake pedal to allow oil inside transmission to
ow in. Pump brake pedal until there is no bubble in fuel.
5) Tighten opening bolt and take out tube once air re-
moval is nished. (Do the same for both left and right)
PERIODIC MAINTENANCE & ADJUSTMENT
8050 OPERATORS MANUAL (122011).indd 142 1/10/2012 9:36:54 PM
