Branson 8050 - Transmission, PTO, and Hydraulic Specifications

• • •
161
Items Specication
Brake Wet Disc, Band Brake
Tranmission
Main shifting Fully Synchronized (4 speed)
Forward / Reverse Method POWER SHUTTLE (hydraulic shuttle)
Gear Shifting (Front x Rear) F12 X R12
Creep Speed (optional) F16 X F16
Travel Speed mph F : 0.95 ~ 18.6 R : 1.13 ~ 21
Travel Speed
(creeper)
mph F : 0.16 ~ 18.6 R : 0.18 ~ 21
PTO
Type Independent P.T.O (6 Spline shaft)
Speed RPM 540 / 760
Hydraulic
System
Type Electric over hydraulic control (position, draft & mixed)
3 point hitch link Telescopic lower link / Telescopic stabilizers
Category Category II
Pump Flow
@ 2500 rpm
Steering 8 GPM (14cc/rev)
Main 14.5 GPM (22cc/rev)
SPECIFICATION
