1) WARNING INDICATOR LAMP
Center warning indicator lamp will light up when trouble occurs
with tractor.
• Error code will be displayed at same time.
2,3) DIRECTION INDICATOR LAMP
The indicator lamp will light up when direction lever is pulled/
pushed to each direction.
4,5,6) F,N,R LAMP
Forward / neutral / reverse lamp will light up when shuttle lever
is postioned in each : forward / neutral / reverse.
F N R
7,8) HEAD LAMP
With the main switch in the “ON” position, turn the light switch
one click to the right for low-beam and pull it up for high-beam.
FUNCTIONS
