7-8 100-214-239 Rev. A
Maintenance
Printer does not print a
report upon request
• A Setup parameter has been
changed
• No report data stored in
buffer since last report
• Run at least one cycle to
capture report data
• Reports not enabled in
Setup
• enableReports inSetup;
run at least one cycle to
capture new report data
• Printer is not set to “On” in
Setup Parameters
• enable Printer in Setup;
run at least one cycle to
capture new report data
• Printer cable is not con-
nected, or printer is ‘offline’
• Correct printer connec-
tions and ready status
• Printer has failed • Fix or replace printer
• Digital Controls have failed • Return unit for repair
• Printer is not compatible
• Use a compatible dot-
matrix printer
Remote Terminal is not
communicating
• RemoteTerminal isnot set to
On in Setup
• enable Remote Terminal
in Setup; run at least one
cycle to capture new
report data
• incorrect or faulty RS-232
cable is used.
•verify,seeSection 4.6.2,
Remote Terminal Con-
nection, on page 4-14.
• Baud Rates do not match
between the system and the
Remote Terminal
• set Baud Rate in Setup;
run at least one cycle to
capture new report data
• Terminal or computer’s com-
munication settings are not
set up properly
• set up the communica-
tion settings to match the
Sonifier’s parameters
User I/O signals are not
working correctly
• User I/O is not configured
correctly
• customer-provided User I/O
components havefailedorare
no longer functioning
• Verify and correct con-
nections - See Section
4.6.6, User I/O Connec-
tion, beginning on page 4-
15
• Outputs of User I/O failed • Return unit for repair
Table 1: System Trouble Analysis Chart
Symptom Probable Cause Corrective Action
