SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
34 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
Switch Configured for
OnO Applications
Actuator Size
E E E
Actuator Size
E thru 
Actuator Size
 
 Limit Switches Standard Standard NA
 Limit  Fixed A- A- Standard
 Limit  Fixed  Mid A- A- B-
 Limit  Fixed  Mid A- A- B-
 Limit  Fixed  Set Mid A- A- B-
 Limit  Fixed  Set Mid NA A- B-
 Heater
Bray oers an optional heater as a field or factory installable option for the
Series  actuator to prevent condensation from forming inside the actuator This
PTC (Positive Temperature Coecient) style heater has a unique temperature
- resistance characteristic The heater self-regulates by increasing its electrical
resistance relative to its temperature The heater does not require external
thermostats or switches to control its heat output
Heater
Figure  Heater installed on a S switch plate
NOTICE
The heater must have a constant power supply to be eective
WARNING
The heater surface can reach temperatures in excess of F [C]
Heater Kit
Heater with flying leads
Mounting Bracket
 Pan Head Screw Phillips Drive
Tools Required
Screwdriver ” [ mm] tip flat blade
Screwdriver No Phillips
