SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
36 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
 Local Control Station
The local control station is a field or factory installable option that gives the operator
the ability to locally drive the Series  actuator with electrical power overriding
the control signal from the process controller The control station has a red (closed)
and green (open) light to provide end-of-travel indication It also has two -position
switches as shown in Figure 
Switch 
Figure  S with Control Station
Switch  lets the operator choose between the following three modes of operation
 Local In this mode using switch  the operator can drive the actuator to open or
close position or stop the actuator overriding any control signal from the process
controller
 O In this mode the actuator can only be operated manually
 Remote In this mode the actuator is controlled remotely from a process
controller
Control Station Kit
Local Control Station Assembly
-UNC x  Socket Head Cap Screws (Qty)
O-rings (Qty)
Gasket
Wiring Diagram
Tools Required
Screwdriver  [ mm] tip flat blade
Screwdriver No Phillips
Hex Key 
