SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
33 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
FIELD OR FACTORY INSTALLABLE OPTIONS
Auxiliary Switches
Auxiliary switch kits are a field or factory installable option for all Series
actuators Switch kits are comprised of dry-contact (voltage free) SPDT mechanical
switches which are used to indicate travel position Switches are arranged into
stacks For Actuator Size E - stack activates prior to switches in stack
For Actuator Size the switch that activates early depends on the
direction of travel
Auxiliary Switches
Figure Fixed auxiliary switches installed in a S actuator
All Series actuators can be fit with one set of fixed auxiliary switches These are a
single set of switches which activate before the travel limit switches Adjustable
auxiliary (Mid-Travel) switches can be fit as single independent switches or in sets If
fitted as a set one of the switches in the set will activate before the other Each
switch set is activated independently from other switch sets
The maximum number and configuration of switches depends on Actuator size and
application of the Series actuator Terminal block availability due to installation of
other options may also limit the maximum number of switches
Switch Configured for
Modulating Application
Actuator Size
E E E
Actuator Size
E thru
Actuator Size
Limit Switches Standard Standard NA
Limit Fixed A- A- Standard
Limit Fixed Mid A- A- B-
Limit Fixed Mid NA NA NA
Limit Fixed Set Mid NA A- B-
Limit Fixed Set Mid NA NA NA
