Bray 70 Series User Manual

SERIES 70 ELECTRIC ACTUATOR
Installation, Operation, and Maintenance Manual
5 of 48
© 2022 BRAY INTERNATIONAL, INC. ALL RIGHTS RESERVED. BRAY.COM
The Information contained herein shall not be copied, transferred, conveyed, or displayed in any manner
that would violate its proprietary nature without the express written permission of Bray International, Inc.
Actuator
Size
Part Number
Torque
lb-in N m
S70-E03 70-E03X-113YZ-TTT 300 34
S70-E06 70-E06X-113YZ-TTT 600 68
S70-E08 70-E08X-113YZ-TTT 800 90
S70-E12 70-E12X-113YZ-TTT 1,200 136
S70-E20 70-E20X-113YZ-TTT 2,000 226
S70-E30 70-E30X-113YZ-TTT 3,000 339
S70-050 70-050X-113YZ-TTT 5,000 565
S70-065 70-065X-113YZ-TTT 6,500 734
S70-130 70-13WX-113YZ-TTT 13,000 1469
S70-180 70-18WX-113YZ-TTT 18,000 2034
Style / Voltage
Voltage
Speed
1/4 Turn
Seconds (60 Hz)
Controller
Imperial Metric
DA NA 120VAC 30* Interposing Relay Board (IRB)
DB NB 220VAC 30* Interposing Relay Board (IRB)
DC NC 24VAC/VDC
1
60 On/O with Controller
DD ND 24VDC 60 No Controller
G0 R0 120VAC 30* Modulating with Servo NXT
G3 R3 24VAC/VDC 60 Modulating with Servo NXT
G4 R4 220VAC 30* Modulating with Servo NXT
F3 Q3 24VAC/VDC 60 On/O NXT Controller
1
S70-050 is only 24VAC
*S70-130, 131 and 180, 181 are 110 seconds
Note: 220VAC units are 230VAC compatable
TTT - Trim
536 Standard
Bray
Red
5F5 Bray
Seacorr
Coating
 PARTS INDENTIFICATION
 Part Numbering System Reference Chart
Series
70
Torque
E03 300 lb-in
E06 600 lb-in
E08 800 lb-in
E12 1200 lb-in
E20 2000 lb-in
E30 3000 lb-in
050 5000 lb-in
065 6500 lb-in
13W 13000 lb-in
18W 18000 lb-in
X - Speed
0 60 sec
1 30 sec
6 110 sec
Product
113 Actuator
Y - Style
G Imperial,
Servo Nxt
R Metric,
Servo Nxt
D Imperial,
IRB
N Metric,
IRB
Z - Voltage
A 120VAC
B 220VAC
C 24VAC/VDC
D 24VDC
0 120VAC
3 24VAC/VDC
4 220VAC
W - Designates The Output Bore Diameter
0 2.5 Inches (63.5mm)
1 1.97 Inches (50 mm)
