42 67XXU USB/Serial Scale Service Manual
COM1
(USB)
BUD.RT 1200 9600 Select COM1 baud rate
2400
4800
9600
19200
38400
BT.FMT 8N1 8N1 Select COM1 byte format (1) 8N1=8 data bits, No parity check
bit, 1 stop bit
7O1 (2) 7O1=7 data bits, 1 Odd parity
check bit, 1 stop bit
7E1 (3) 7E1=7 data bits, 1 Even parity
check bit, 1 stop bit
OUT.MD
none PRt.cd Select COM1 output mode (1) NONE=no communication
CONT (2) CONT=continuously output
PRINT (3) PRINT=output after [PRINT] key
is pressed
CMD (4) CMD=output after a request
command is received
PRT.CD (5) PRT.CD= output after [PRINT]
key is pressed or request command
received
STABL (6) STABL=Sends output
automatically after scale is stable.
Note: use PRINT or CMD to output
data, the scale must be stable
auto-1 **(7) AUTO-1=Weight is
automatically transmitted after
weight is removed from the scale
platform. The last "stable" weight
prior to removing the item will be
"send", as soon as the display
d iv isi on s(i .e . 5 d) .
Note: use PRINT or CMD to output
data, the scale must be stable.
**Note: If PRINT, STABL, ST.NLD, LNLD or CMD are used to output data, the scale must be stable.
USER
SubMenu1 SubMenu2 Option Default Parameter Description Comment
