5.3 Setup Menu Parameters
This section provides more detailed descriptions of the selections found in the Setup
Menu.
The menu charts show the flow of the parameters and also provide a quick reference
to the parameters within the menu.
The menu tables show the submenus, options and default parameter in LCD display
format to coincide with the actual display.
5.3.1 CONFG Menu
Figure 5.1 CONFG Menu Chart
The figure above is an illustration of the available menus with the CONFG menu and
the choices within those menus. Refer to Table 5.2 for explanations of the menu
choices.
CF.ON
CF.OFF
PRI.Ut
100 – 25,000
SECD.N
RESET REGUL
100 – 20,000
PRIM.N PRIM.D
MOTION OVER.D UNITS
1 - 255 0 - 100
0.2 0.5 1 2 5
0.0001 0.0002 0.0005 0.001 0.002
0.005 0.01 0.02 0.05 0.1
ZRO.PT FLTER
FUNC
10.DSP
* only appears if “Regul” is set to None
No Yes
none USA Canada Europe
kg lb
No Yes kg lb oz lb:oz g
No Yes
IZSM IN.IZS * OV.IZS * SAZSM AZSM
0 - 100 0 - 100
0 - 100
WEGHT CAL.ZR LST.Z.T
DP.OVR CAL.ZR LST.Z.TWEGHT
0 - 255
0 - 255
0 - 255
FT1.TH FT1.ST FT2.TH FT2.ST
Weak Midle Stong
Yes No
HOLD COUNT COMPR GE.CAL WT.ADJ
