67XXU USB/Serial Scale Service Manual 17
2.4 Desktop and Wall Display Mounting
The indicator is connected to the front of the 67XXU. It can be removed however to
accommodate mounting on a wall or desk. Plug the display cable into the DISPLAY
connector.
Figure 2.21 Indicator Desk Mount
Figure 2.22 Indicator Wall Mount
