67XXU USB/Serial Scale Service Manual 37
Table 5.2 CONFG Menu Choices and Explanations
CONFG
SubMenu1 SubMenu2 Option Default Parameter Description Comment
CF.ON
CF.OFF
Seal switch position The display will show whether the
seal switch is in the ON or Off
position. This parameter can’t be
changed within the software.
RESET NO NO Reset Confg menu
parameters to default
setting
YES
REGUL none USA Select the standard in
which the scale will
comply: USA, Canada,
Europe
*None = not legal for trade.
USA
Canda
Eurpe
PRIM.N 100 - 20000 Primary full scale value Default full scale value will depend
on capacity of scale.
*If (REGUL) ≠ none, the max is
10,000
PRIM.D 0.0001 The division value under
primary unit
Default division size will depend on
capacity of scale.
The division value under second
unit is automatically determined by
the indicator according to the
division value under primary unit.
0.0002
0.0005
0.001
0.002
0.005
0.01
0.02
0.05
0.1
0.2
0.5
1
2
5
To Next Page
