BRIDEX Rudolf R-DPA96 A User Manual

112
RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-Module 3 ( RS485 - JBUS/MODBUS
®
)
COMMUNICATION
Decimal Hexa. Number Text Unit
address address of words
3342 D0E 1 Query! : phase-to-phase residual value :
0 : no
5: U12
6: U23
7: U31
3343 D0F 2 Value
3345 D11 1 Query! : phase-to-neutral residual value :
0 : no
22 : V1
23 : V2
24 : V3
3346 D12 2 Value
3348 D14 2 Duration ms
3350 D16 1 Day
3351 D17 1 Month
3352 D18 1 Year
3353 D19 1 Hour
3354 D1A 1 Minute
3355 D1B 1 Second
Decimal Hexa. Number Text Unit
address address of words
3356 D1C 1 Query! : phase-to-phase residual value :
0 : no
5: U12
6: U23
7: U31
3357 D1D 2 Value
3359 D1F 1 Query! : phase-to-neutral residual value :
0 : no
22 : V1
23 : V2
24 : V3
3360 D20 2 Value
3362 D22 2 Duration ms
3364 D24 1 Day
3365 D25 1 Month
3366 D26 1 Year
3367 D27 1 Hour
3368 D28 1 Minute
3369 D29 1 Second
LAST 10 VOLTAGE DIPS EVENT LOG / SAG (FUNCTION 3)
Voltage dip n-2
Voltage dip n-3
