TECHNICAL CHARACTERISTICS
Analog outputs
Load resistance 0 to 600 Ohms
Response time 1 sec
Galvanic insulation 2.5 kV
Accuracy (full scale) 0.5 %
UL 61010-1 N° le : E25 7746
Certification
PROGRAMMING
PROGRAMMING OF N° 2, 3 AND 4 ANALOG OUTPUT
Proceed as for number 1 analog output. Press t to return to network programming (Net) or to pass to number 2
analog output programming or press for 3 seconds on PROG to quit programming.
RUDOLF - Ref. : 876 586 A
Out 1 20 mA … Out 4 20 mA Analogue outputs nos. 1 to 4
TYPE Allocation of signal type 0-20 mA, 4-20 mA
0/20 Relay status control via RS 485
4/20 Signal 4-20 mA
30 VDC 30 VDC feed to supply the optocoupler inputs of the 2IN/2OUT module
I1, I2, I3 Current I1, I2, I3
In Neutral current
U12, U23, U31 Phase-to-phase voltage U12, U23, U31
V1, V2, V3 Phase-to-neutral voltage V1, V2, V3
ΣP Total active power
ΣQ Total reactive power
ΣS Total effective power
F Frequency
ΣPFL Power factor (lagging)
ΣPFC Power factor (leading)
Out 1 20 mA LV …Out 4 20 mA LV Value at 0 or 4 mA
Out 1 20 mA HV …Out 4 20 mA HV Value at 4-20 mA
/ Value displayed (e.g. : A = Amps)
K Kilo (e.g. : kA = kilo amps)
M Mega (e.g. : MA = mega amps)
I SYS, U SYS, V SYS Current, phase to phase voltage, phase to neutral voltage system
GLOSSARY OF ABBREVIATIONS
R-DPA96 A/AN - R-Module 4 (0/4 - 20 mA)
138
