63
RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-MODULE 3 (RS485 - JBUS/MODBUS
®)
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
Address available with the Monitoring or Control/Command option
Decimal Hexa. Number Text Unit
address address of words
866 362 2 Input pulse meter 1
868 364 2 Input pulse meter 2
870 366 2 Number of impulse meters
872 368 2 Current alarm :
0 : no alarm
1 : I
2 : U
3: ΣP+
4: ΣQ+
5: ΣS
6: F
7 : ΣPFL
8 : thd I
9 : thd U
10 : In
11 : HOUr
12 : V
13 : thd In
14 : thd V
15 : ΣP-
16 : ΣQ-
17 : Σ PFC
874 36A 2 Current overrun :
0 : no alarm
1 : I
2 : U
3: ΣP+
4: ΣQ+
5: ΣS
6: F
7 : ΣPFL
8 : thd I
9 : thd U
10 : In
11 : HOUr
12 : V
13 : thd In
14 : thd V
15 : ΣP-
16 : ΣQ-
17 : Σ PFC
876 36C 2 Number of inputs-outputs -
Low-order: number of inputs
High-order: number of outputs
878 36E 2
Status of inputs-outputs
0 : status input 1 (0 = open, 1 = closed)
bit 1 : status input 2 (0 = open, 1 = closed)
bit 2 : status input 3 (0 = open, 1 = closed)
bit 3 : status input 4 (0 = open, 1 = closed)
bit 4 : status input 5 (0 = open, 1 = closed)
bit 5 : status input 6 (0 = open, 1 = closed)
bit 16 : status output 1 (0 = open, 1 = closed)
bit 17 : status output 2 (0 = open, 1 = closed)
bit 18 : status output 3 (0 = open, 1 = closed)
bit 19 : status output 4 (0 = open, 1 = closed)
bit 20 : status output 5 (0 = open, 1 = closed)
bit 21 : status output 6 (0 = open, 1 = closed)
