R-DPA96 A/AN - R-Module 4 (0/4 - 20 mA)
132
RUDOLF - Ref. : 876 586 A
INSTALLATION
DPA96 342 A
1
DPA96 343 A
OUT1
OUT2
OUT3
OUT4
5678
+-+-
5678
+-+-
Fix the module
2
This R-DPA96 A/AN must be switched off.
DPA96 435 A
5678
+-+-
OUT1
OUT2
3
When using the four outputs, the two modules must
be installed in the two left-hand positions as shown.
CONNECTION
4
Follow indications when connecting the terminal.
Switch on voltage supply.
5
