RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-MODULE 3 (RS485 - JBUS/MODBUS
®)
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED (FUNCTION 3)
Table of values without allocated current and voltage winding ratios on 1 word
Decimal Hexa. Number Text Unit
address address of words
1792 700 1 Phase 1 current mA
1793 701 1 Phase 2 current mA
1794 702 1 Phase 3 current mA
1795 703 1 Neutral current mA
1796 704 1 Phase to phase voltage U12 V/10
1797 705 1 Phase to phase voltage U23 V/10
1798 706 1 Phase to phase voltage U31 V/10
1799 707 1 Phase to neutral voltage phase 1 V/10
1800 708 1 Phase to neutral voltage phase 2 V/10
1801 709 1 Phase to neutral voltage phase 3 V/10
1802 70A 1 Frequency Hz/100
1803 70B 1 Σ active power +/- kW/100
1804 70C 1 Σ reactive power +/- kvar/100
1805 70D 1 Σ apparent power +/- kVA/100
1806 70E 1 Σ power factor L/C
-: leading and +: lagging 0.001
1807 70F 1 Active power phase 1 +/- kW/100
1808 710 1 Active power phase 2 +/- kW/100
1809 711 1 Active power phase 3 +/- kW/100
1810 712 1 Reactive power phase 1 +/- kvar/100
1811 713 1 Reactive power phase 2 +/- kvar/100
1812 714 1 Reactive power phase 3 +/- kvar/100
1813 715 1 Apparent power phase 1 kVA/100
1814 716 1 Apparent power phase 2 kVA/100
1815 717 1 Apparent power phase 3 kVA/100
1816 718 1 Power factor phase 1 L/C
-: leading and +: lagging 0.001
1817 719 1 Power factor phase 2 L/C
-: leading and +: lagging 0.001
1818 71A 1 Power factor phase 3 L/C
-: leading and +: lagging 0.001
1819 71B 1 avg I1 mA
1820 71C 1 avg I2 mA
1821 71D 1 avg I3 mA
1822 71E 1 avg Σ active power + kW/100
1823 71F 1 avg Σ active power - kW/100
1824 720 1 avg Σ reactive power + kvar/100
1825 721 1 avg Σ reactive power - kvar/100
1826 722 1 avg Σ apparent power kVA/100
1827 723 1 max/avg I1 mA
1828 724 1 max/avg I2 mA
1829 725 1 max/avg I3 mA
1830 726 1 max/avg Σ active power + kW/100
1831 727 1 max/avg Σ active power - kW/100
1832 728 1 max/avg Σ reactive power + kvar/100
1833 729 1 max/avg Σ reactive power - kvar/100
1834 72A 1 max/avg Σ apparent power kVA/100
1835 72B 1 Active energy + < 10000 kWh
