R-DPA96 A/AN - R-Module 3 ( RS485 - JBUS/MODBUS
®
)
COMMUNICATION
PULSE METERS VALUES
Input meters
R-DPA96 A/AN reply: identical to the message sent.
Size of this zone: 12 words (decimals) or C (hexadecimals)
RESET TO ZERO: ENERGY METERS AND MAX. VALUES (FUNCTION 6)
SAVED COMMAND (RESET)
The following command should be done to save
programming parameters changes for R-DPA96 num-
ber 5.
NB :
R-DPA96 A/AN will not reply to this command.
NB:
To reset several parameters to zero, add the corre-
sponding gure indicated in the “text” column.
Example: reset Max P+ and kvarh + to zero:
2 + 100 = 102 (Hex)
Example:
To reset all values for R-DPA96 number 5 to zero, the
following frame should be sent:
Decimal Hexa. Number Text Unit
address address of words
2560 A00 2 Input E1, option ES 1
2562 A02 2 Input E2, option ES 1
2564 A04 2 Input E3, option ES 2
2566 A06 2 inputE4, option ES 2
2568 A08 2 Input E5, option ES 3
2570 A0A 2 Input E6, option ES 3
Slave
05
Function
06
High-order
address
04
Low-order
address
00
High-order
word N°
10
Low-order
word N°
00
CRC 16
84BE
Slave
05
Function
06
High-order
address
06
Low-order
address
00
Values
0000
CRC 16
88C6
