GLOSSARY OF ABBREVIATIONS
Out 1… Out 2 Pulse output 1 and 2
TYPE Pulse output allocation
EA+ Positive active power (kWh+)
ER+ Positive reactive power(kvarh+)
ES Effective power(kVAh)
EA- Negative active power(- kWh)
ER- Negative reactive power (- kvarh)
VAL Pulse value
DUR Pulse duration
THD Total harmonic distortion
H03 … H25 Harmonic numbers 3 to 25
TECHNICAL CHARACTERISTICS
Harmonics
Updating of % 1 sec
Accuracy ± 0.5 point
Minimum value displayed 1.6 %
Pulse outputs
Reed relays max. 100 V DC - 0.5 A - 10 VA
N° of operations ≤ 10
8
Galvanic insulation (AC insulation voltages) 2.5 kV
Certification
UL 61010-1 N° le : E25 7746
RUDOLF- Ref. : 876 585 A
R-DPA96 A/AN - R-Module 2 (kWh - kvarh - KVAh, Harmonics)
52
