33
RUDOLF - Ref. : 876 583 A
TECHNICAL CHARACTERISTICS
CASE
Dimensions: 96 x 96 x 60 mm
or 96 x 96 x 80 mm with all optional modules (DIN 43700)
Connection: via 2.5 mm
2
disconnectable terminals
(voltage and others) and 6 mm
2
xed terminals (current)
IP index: IP52 (front panel) and IP30 (case)
Weight: 400 gr.
DISPLAY
Type : Backlit LCD display
MEASUREMENTS
Three-phase (3 or 4 wires), two-phase (2 wire) and single-phase networks
VOLTAGE (TRMS)
Direct measurement: from 18 to 700 V AC (phase/phase)
from 10 to 404 V AC (phase/neutral)
Measurement via PT: • Primary: up to 500 kV
• Secondary: 60, 100, 110, 115, 120, 173 and 190 V AC
Display and resolution from 0 to 500.0 kV
Permanent overload: 760 V AC
Update period: 1 second
CURRENT (TRMS)
Via CT with: • Primary: up to 10000 A
• Secondary: 1 or 5 A
Minimum measuring current 10 mA
Input consumption: < 0.3 VA
Display: from 0 to 11 kA (1.1 times the primary value)
permanent overload: 10 A
intermittent overload: 10 In / 1 second
Update period: 1 second
Maximum ratio KI x KU: 10 000 000
POWER
Total: 0 to 8000 MW/Mvar/MVA
Update period: 1 second
FREQUENCY
from 45,0 to 65,0 Hz
Update period: 1 second
ENERGY / MEASUREMENT ACCURACY
Current: 0.2 % from 10 to 110 % / In
Voltage: 0.2 % from 140 to 700 V AC
Power: 0.5 % of full scale (-90° à + 90°)
Power factor: 0.5 % for 0.5 < FP < 1
Frequency: 0.1 % from 45 to 65 Hz
Active energy metering: ± 0.5 % from 0.02 to 1,2 In with PF = 0.5 L or 0.8 C
(class 0.5S IEC 62053-22)
Reactive energy metering: ± 2% from 0.1 to 1,2 In with sinϕ = 0.5 L or C
(class 2 IEC 62053-23)
AUXILIARY SUPPLY
110 to 440 V AC 50/60 Hz ± 10 %
120 to 350 V DC ± 20 %
12 to 48 V DC -6 % / + 20 %
Consumption: < 10 VA
R-DPA96 A/AN
