Page #42 background imageLoading...
Page #42 background image
TECHNICAL CARACTERISTICS
Reed relays max. 100 V DC - 0.5 A - 10 VA
of operations 10
8
Galvanic insulation (AC insulation voltage) 2.5 kV
Certification
UL 61010-1 le : E25 7746
PULSE OUTPUT N°2 PROGRAMMING
Proceed as for output 1
GLOSSARY OF ABBREVIATIONS
Out 1… Out 2 Pulse output 1 and 2
TYPE Pulse output allocation
EA+ Positive active power (kWh+)
ER+ Positive reactive power(kvarh+)
ES Effective power(kVAh)
EA- Negative active power(- kWh)
ER- Negative reactive power (- kvarh)
VAL Pulse value
DUR Pulse duration
THD Harmonic distortion rate
H03 H25 Harmonic numbers 3 to 25
R-DPA96 A/AN - R-MODULE 1 (kWh - kvarh - kVAh)
PROGRAMMING - TECHNICAL CHARACTERISTICS
GLOSSARY OF ABBREVIATIONS
RUDOLF - Ref. :876 584 A
42
