INSTALLATION
R-DPA96 342 A
CONNECTION
R-DPA96 343
Fix the module
R-DPA96 344
1 2 3 4
OUT1
OUT2
Follow indications when connecting the ter
minal. Switch on voltage supply.
This R-DPA96 A/AN must be switched off.
1
2
3
4
RUDOLF - Ref. :876 584 A
37
R-DPA96 A/AN - R-Module 1 ( kWh -kvarh - kVah)
37
