151
RUDOLF Ref. : 876 587 A
TECHNICAL CHARACTERISTICS
Relay outputs
Relay max. 230 V AC – 5 A – 1150 VA
N° of operations ≤ 10
5
Galvanic insulation 2.5 kV
Response time 1s
Certification
UL 61010-1 N° le : E25 7746
Optocoupler inputs
Max. direct voltage 30 V DC
Min. direct voltage 10 V DC
Max. inverse voltage 30 V DC
Galvanic insulation 3 kV
Min. pulse duration 10 ms
Max number of operations 10
8
GLOSSARY OF ABBREVIATIONS
Out 1 A-Cd… Out 6 A-Cd Relay outputs 1 to 6
In1 … In 2 Optocoupler inputs 1 to 6
TYPE Output relays allocation
CDE Relay status control via RS 485
I Current I1, I2, I3
In Neutral current
U Phase-to-phase voltage U12, U23, U31
V Phase-to-neutral voltage V1, V2, V3
ΣP+ Total positive active power
ΣP- Total negative active power
ΣQ+ Total positive reactive power
ΣQ- Total negative reactive power
ΣS Total effective power
F Frequency
ΣPFL Power factor (lagging)
ΣPFC Power factor (leading)
THD I Current harmonic distortion (phases)
THD In Current harmonic distortion (neutral)
THD U Phase-to-phase harmonic distortion
THD V Phase-to-neutral harmonic distortion
HOUr Hour meter
CD-t Relay status control via RS 485 with return to unenergised state
Out 1 Ht…Out 6 Ht Alarm upper threshold
Out 1 Lt … Out 6 Lt Alarm lower threshold
/ Value displayed (e.g. : A = Amps)
K Kilo (e.g. : kA = kilo amps)
M Mega (e.g. : MA = mega amps)
Out 1 HYST … Out 6 HYST Hysteresis from 0 to 99%
Out 1 TEMPO … Out 6 TEMPO Relay switching time delay from 0 to 999 s.
Out 1 RELAY … Out 6 RELAY Unenergised output relay
NC Relay normally off
NO Relay normally on
R-DPA96 A/AN - R-Module 5 (2 Inputs / 2 Outputs)
