BRIDEX Rudolf R-DPA96 A User Manual

111
RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-MODULE 3 (RS485 - JBUS/MODBUS
®)
COMMUNICATION
Decimal Hexa. Number Text Unit
address address of words
22 : V1
23 : V2
24 : V3
25 : thd In
26 : thd V1
27 : thd V2
28 : thd V3
29 : ΣP-
30 : ΣQ-
31 : ΣPFC
3219 C93 2 Upper threshold value
3221 C95 1 Duration s
3222 C96 1 Day
3223 C97 1 Month
3224 C98 1 Year
3225 C99 1 Hour
3226 C9A 1 Minute
3227 C9B 1 Second
LAST 10 ALARMS EVENT LOG (FUNCTION 3)
Alarm n-10
LAST 10 VOLTAGE DIPS EVENT LOG / SAG (FUNCTION 3)
Voltage dip n-1
Zone size: 140 words (decimal) or 8C (hexadecimal).
Decimal Hexa. Number Text Unit
address address of words
3328 D00 1 Query! : phase-to-phase residual value :
0 : no
5: U12
6: U23
7: U31
3329 D01 2 Value
3331 D03 1 Query! : phase-to-neutral residual value :
22 : V1
23 : V2
24 : V3
3332 D04 2 Value
3334 D06 2 Duration ms
3336 D08 1 Day
3337 D09 1 Month
3338 D0A 1 Year
3339 D0B 1 Hour
3340 D0C 1 Minute
3341 D0D 1 Second
