TECHNICAL CHARACTERISTICS
Optocoupler input
Max. direct voltage 30 V DC
Min. direct voltage 10 V DC
Max. inverse voltage 30 V DC
Galvanic insulation 3 kV
Min. pulse duration 1s
Max number of operations 10
8
Memory size 512 ko
Certification
UL 61010-1 N° le : E25 7746
RUDOLF - Ref. : 876 588 A
R-DPA96 A/AN - R-Module 7 (Memory)
MEMO Memory module
P+ Positive power consumption demand
P- Active power consumption demand
Q+ Positive reactive power consumption demand
Q- Negative reactive power consumption demand
YES Yes
NO No
TOP Synchronisation signal
INT Internal
EXT External
tIME Synchronisation period
dAtA Event storing
SAG Voltage dip
HySt Hysteresis
SWELL Overvoltage
dAtE days / months / years
tIME hours / minutes / seconds
GLOSSARY OF ABBREVIATIONS
169

BRIDEX Rudolf R-DPA96 A Specifications

General

Brand	BRIDEX
Model	Rudolf R-DPA96 A
Category	Measuring Instruments
Language	English
