INSTALLATION
DPA96A 342 A
CONNECTION
1
DPA96A 343 A
Fix the module
2
This R-DPA96 A/AN must be switched off.
DPA96A 433 A
3
RUDOLF - Ref. : 876 587 A
R-DPA96 A/AN - R-Module 5 (2 Inputs / 2 Outputs)
142
12 11 10 9
OUT1
1
1
OUT2
2
2
+ - + -
IN2
IN1
N
16 15 14 13
