BRIDEX Rudolf R-DPA96 A User Manual

PULSE OUTPUT N°2 PROGRAMMING
Proceed as for output n°1
PULSE OUTPUT N°1 DURATIONS - Example: DUR = 200 ms
x 1
x 1 (200 ms)
x 2 (300 ms)
x 3 (400 ms)
x 4 (500 ms)
x 5 (600 ms)
x 6 (700 ms)
x 7 (800 ms)
x 8 (900 ms)
x 9 (100 ms)
x 1
confirm
RUDOLF- Ref. : 876 585 A
50
R-DPA96 A/AN - R-Module 2 (kWh - kvarh - KVAh, Harmonics)
PROGRAMMING
