RUDOLF - Ref. : CDR 27 028_gb
R-DPA96 A/AN - R-Module 3 ( RS485 - JBUS/MODBUS
®
)
COMMUNICATION
LIST OF PARAMETERS TO BE DISPLAYED OR PROGRAMMED (FUNCTION 3, 6 OR 16)
Decimal Hexa. Number Text Unit
address address of words
13 : V3
14 : F
15 : ΣPFC
529 211 1 Value at 0 or 4 mA from analog output OUT 1 –
530 212 1 Unit at 0 or 4 mA from analog output OUT 1 : –
0 : /
1 : k
2 : M
531 213 1 Value at 20 mA from analog output OUT 1 –
532 214 1 Unit at 20 mA from analog output OUT 1: –
0 : /
1 : k
2 : M
533 215 1 Type of analog output OUT 2 : –
0 : 0/20 mA
1 : 4/20 mA
2 : 30 V
534 216 1 Output allocation analog OUT 2: –
0 : I1
1 : I2
2 : I3
3 : In
4 : U12
5 : U23
6 : U31
7 : ΣP
8 : ΣQ
9 : ΣS
10 : ΣPFL
11 : V1
12 : V2
13 : V3
14 : F
15 : ΣPFC
535 217 1 Value at 0 or 4 mA from analog output OUT 2 –
536 218 1 Unit
at 0 or 4 mA from analog output OUT 2 : –
0 : /
1 : k
2 : M
537 219 1 Value at 20 mA from analog output OUT 2: –
538 21A 1 Unit at 20 mA from analog output OUT 2: –
0 : /
1 : k
2 : M
539 21B 1 Type of analog output OUT 3:
0 : 0/20 mA
1 : 4/20 mA
2 : 30 V –
540 21C 1 Output allocation analog OUT 3: –
0 : I1
1 : I2
2 : I3
3 : In
4 : U12
5 : U23
6 : U31
