4-3
Model ES24
1. Cooking Well: Holds 70# cooking oil.
Normal operating pressure is 12-14
psi.
2. Handle and Cover Assembly: Seals
the cooking well during pressure fry-
ing. Safely locks the cover in place
while pressure is in the cooking well.
Safely diverts steam toward the rear of
the appliance in the event the O-ring
leaks.
Never operate the pres-
sure fryer with a damaged
or defective cover assembly. It is recom-
mended that the cover assembly and its
operation be inspected routinely by an
authorized service representative.
3. Combustion Exhaust Flue: Safely
conducts combustion exhaust prod-
ucts into a vented hood area.
4. Cooking Well Exhaust Stack: Safely
conducts steam from the cooking pro-
cess into a vented hood area.
5. ON/OFF Switch: Applies and removes
electrical power to and from the appli-
ance.
6. Smart Touch Touchscreen Control:
Provides a human machine interface
for all fryer operations.
7. Front Cabinet Door: Allows access to
the fryer cabinet for condensate pan,
filter pan and oil reservoir tank
removal.
8. Filter Pan: Holds filter components
and filtering compound used to filter
hot oil and allows capture and efficient
removal of crumbs produced during
the cooking process.
Never operate the pres-
sure fryer without the fil-
ter pan in place and the piping securely
connected. HOT OIL may spill out or leak
as a result. This unit has integrated
sensors to indicate if filter pan is
installed completely.
Surfaces may be
extremely HOT during fil-
tering operation. Always wear protective
gloves and clothing to prevent burns
when accessing the filter pan. Allow the
filter pan to cool to room temperature
before removing its contents at every
possible opportunity.
HOT OIL! DO NOT use this
container to transport
HOT OIL. HOT OIL could splash causing
serious burns.
9. Condensate Pan: Holds condensa-
tion drained from the exhaust tank.
Check liquid level several times daily.
Empty as needed.
Water and HOT OIL
DO NOT mix. DO
NOT
pour contents of condensate
pan into cooking well or filter pan.
HOT OIL could splash causing seri-
ous burns.
10. Oil Replenishment Reservoir: Stores
fresh oil for automatic replenishment
of the oil when it is low.
11. Oil Management Pump: Allows for
safe filtering, replenishment and dis-
charge of the oil.
12. Gas Shutoff Valve: (Gas units only)
Allows isolation of the appliance from
the gas utility.
broaster.com Manual #21469 621 Rev 11/23
