Brocade Communications Systems FastIron SuperX User Manual

6 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Hardware features
1
Figure 2 shows the FSX chassis and the slots into which you can install the various modules and
power supplies.
FIGURE 2 FSX chassis slots
Figure 2 also shows an electrostatic discharge (ESD) connector, into which you can plug an ESD
wrist strap to ground yourself while handling and installing modules.
DANGER
For safety reasons, the ESD wrist strap should contain a series 1 meg ohm resistor.
1Slot 1
2Slot 2
3Slot 3
4Slot 4
5Slot 5
6Slot 6
7Slot 7
8Slot 8
9Slot 9
10 ESD connector
11 Fan tray
DC OK ALMAC OK
SYSEJECT
Odd
Even
Lnk
Lnk
Odd
Even
POE
424C
424F
8X-12GM-4
Console
Pwr
Lnk
Odd
Even
Odd
Even
Lnk
7
5
3
1 2 11
4
6
8
9
10
FastIron SuperX
