Atmospheric Single-Arm Robot Safety

User’s Manual Safety Labels

Brooks Automation

Revision 1

2-11

High Voltage Label

Pinch Point Label for SEMI S2 Systems

Fuse Label

The fuse safety label is attached adjacent to the power supply input on the con-

troller.

The high voltage-warning label is attached to

the controller.

The pinch point label is attached to the top

of the robot body. Possible pinch points are

located near any moving arm extension or

the Z axis. It is hazardous to put your hand

in the space at either end of the robot.

Caution - Risk of Fire T

Replace with R5A 250V Fuse
