Safety Atmospheric Single-Arm Robot

Safety Labels User’s Manual

Brooks Automation

2-12 Revision 1

Underwriter Lab Label

Manufacturing Labels

The controller manufacturing label lists the power rating. It is located adjacent

to the power supply input on the controller.

The robot manufacturing label is located on the left front of the robot.

The Underwriter Lab label is attached to the side

panel of the power supply input on the controller.
