Installation Atmospheric Single-Arm Robot

Alignment and Calibration User’s Manual

Brooks Automation

3-24 Revision 1

Alignment and Calibration

The Brooks Automation Atmospheric Single-Arm Robot must be aligned with the

system that it will be operating in. Note that even a small misalignment can interfere

with proper product operation and may cause wafer breakage.

The user must perform a complete alignment as part of installing the product in a sys-

tem. Additionally, proper alignment should be verified after servicing the product.

Refer to details in this chapter.

CAUTION

Do not attempt to use the Atmospheric Single-Arm Robot until the

alignment procedures have been completed.
