Brother HL-2250DN Service Manual

5-9
Confidential
16) Duplex Setting (ON/OFF)
Switch the ON/OFF of the duplex setting. Whenever you switch this mode, the setting is
changed over from the present one to the other.
You can verify the setting change by LEDs when releasing the [Go] button. When the
setting is completed, the printer return to the ready state.
17) Paper Size Setting (A4/Letter)
Switch the ON/OFF of the paper size setting (A4/Letter) of the printer. Whenever you
switch this mode, the setting is changed over from the present one to the other.
You can verify the setting change by LEDs when releasing the [Go] button. When the
setting is completed, the printer return to the ready state.
18) Printing for Maintenance
This is to print a list of all maintenance information including printer coverage
information. (There is not the development of each national language, and only English.)
Display terms is as follows.
LED Setting of duplex
Toner LED and Drum
LED light for one
second
Duplex OFF
→ Duplex ON
Not light Duplex ON
→ Duplex OFF
LED Setting of paper size
Toner LED and Drum
LED light for one
second
A4
→ LETTER
Not light LETTER
→ A4
Series Name Model name of printer
Serial Number Serial number of printer
Count. Rom Version Rom version of printer
Device Status Page Count, Drum Count, Average Coverage
The maximum count for each item is 1 million times.
Drum Information Estimated Pages Remaining, % of Life Remaining.
Total Pages Printed
*1
Previously Used Toner, Current Toner. The maximum
count for each item is 1 million times.
% of Toner Life Remaining.
Total Pages Printed Total Pages Printed (Tray 1, Manual Feed and Duplex
Tray).
The maximum count for each item is 1 million times.
The information above is not cleared when replacing the
PF kit.
Total Pages Printed The number of A4/Letter, Legal/Folio, B5/Executive,
Envelope, A5 and other paper types used. The
maximum count for each item is 1 million times.
Total Pages Printed
The number of Plain/Thin/Recycled, Thick/Thicker/Bond,
Envelopes/Env. Tick/Env. Thin, Label and Hagaki types
used. The maximum count for each item is 1 million times.
Total Paper Jams The number of paper jam occurrence in each of the
Tray1, Inside, Rear and DX Tray. The paper jam occurs
when the printer is turned ON is not counted.

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
