Brother HL-2250DN Service Manual

2-46
Confidential
4.8.5 Low voltage power supply PCB ASSY failure
4.9 Other Problems
4.9.1 The printer is not turned on, or the LED indication does not appear.
4.9.2 Fuser fan does not rotate.
User Check
• Turn the power off and on.
Step Cause Remedy
1
Harness connection failure of low
voltage power supply PCB ASSY
Check the harness connection of the low
voltage power supply PCB ASSY, and
reconnect it.
2
Low voltage power supply PCB
failure
Replace the low voltage power supply
PCB ASSY. Then, reset the irregular
power supply detection counter following
the procedure described in "3.1 Reset of
Irregular Power Supply Detection
Counter" in Chapter 4.
3 Main PCB failure Replace the main PCB ASSY.
CAUTION :
• The irregular power supply detection error (After blinking the Toner/Drum/Error/Ready
LED, the Toner/Drum/Error LED light up by pressing the [Go] button once. ) occurs
when there is a large distortion in the power supply voltage supplied to the printer.
In this case, if the same power supply is used, the same error may occur even when
the low voltage power supply PCB ASSY is replaced. Ask the user to review the
installation environment.
User Check
• Replace the AC power cord.
Step Cause Remedy
1
Harness connection failure of panel
PCB ASSY
Reconnect the harness of the panel PCB
ASSY correctly.
2 Panel PCB failure Replace the panel PCB ASSY.
3
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply
PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Harness connection failure of the
fuser fan
Reconnect the harness of the fuser fan
correctly.
2 Fuser fan failure Replace the fuser fan.
3
Harness connection failure of high
voltage power supply PCB
Reconnect the harness of the high
voltage power supply PCB ASSY.
4
High voltage power supply PCB
ASSY failure
Replace the high voltage power supply
PCB ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
