Brother HL-2250DN Service Manual

2-47
Confidential
4.9.3 Main motor failure
4.9.4 Front cover open
Front cover opened
4.9.5 Back cover open
Back cover opened
Step Cause Remedy
1
Flat cable connection failure of the
main motor
Check the flat cable connection of the
main motor, and reconnect it.
2 Main motor failure Replace the main motor.
3
Low voltage power supply PCB
ASSY failure
Replace the low voltage power supply
PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
User Check
• Check if the front cover is closed certainly.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB ASSY
(Front cover sensor is mounted in
high voltage power supply PCB
ASSY.)
Check the harness connection of the high
voltage power supply PCB ASSY, and
reconnect it.
2
Part pressing the front cover sensor
is broken, which is provided at
inside of front cover
Replace the front cover ASSY.
3
Front cover sensor failure Check the registration front sensor and
registration rear sensor performance
following the procedure in "Operational
Check of Sensors" (Chapter 5).
If any problem occurs, replace the high
voltage power supply PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
User Check
• Check if the back cover is closed certainly.
• Install the duplex tray certainly.
Step Cause Remedy
1
Harness connection failure of paper
eject sensor PCB ASSY
Check the harness connection of the
paper eject sensor PCB ASSY, and
reconnect it.
2
Part pressing the back cover sensor
is broken, which is provided at
inside of back cover
Replace the back cover ASSY.
3
Part pressing the back cover sensor
is broken, which is provided at
inside of duplex tray
Replace the duplex tray.
4
Back cover sensor failure Replace the paper eject sensor PCB
ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
