Brother HL-2250DN Service Manual

1-1
Confidential
CHAPTER 1 SPECIFICATIONS
1. SPECIFICATIONS LIST
1.1 General
Specifications are subject to change without prior notice.
Model HL-2130 HL-2135W HL-2220 HL-2230
Print method Electrophotographic / Laser
Resolution
600 x 600 dpi, HQ1200 (2400 x 600 dpi) quality
Print speed Up to 20/21 ppm (A4/Letter size) Up to 24/24 ppm
(A4/Letter size)
* When loading A4 or Letter-size paper from the paper tray.
Warm-up time From Sleep mode Less than 7 seconds at 23°C (73.4 F)
From Power
OFF:
→ ON
Less than 25
seconds at
23°C (73.4 F)
Less than 26
seconds at
23°C (73.4 F)
Less than 25 seconds at
23°C (73.4 F)
First print time From Ready mode Less than 10 seconds Less than 8.5
seconds
From Sleep mode Less than 19 seconds Less than
16.5 seconds
CPU ARM9 200MHz
Memory 8 MB 16 MB 8 MB
Interface Hi-Speed
USB 2.0
Hi-Speed USB 2.0,
IEEE802.11b/g
(Infrastructure
Mode/Adhoc Mode)
Hi-Speed USB 2.0
Power
Consumption
Peak 1056W
Printing Average: Approx. 421 W Average:
Approx. 495 W
Ready Average: Approx. 62 W Average:
Approx. 65 W
Sleep,
Wireless LAN: ON
N/A Average:
Approx. 2.8 W
N/A
Deep Sleep Average:
Approx. 0.8 W
Average:
Approx. 0.9 W
Average:
Approx. 0.8 W
Average:
Approx. 0.9 W
Noise level Sound
pressure
Printing LWAd = 53 dB(A)
Ready LWAd = 31 dB(A)
Sound
power
Printing For U.S.A./China LWAd = 6.60 B(A)
Except for U.S.A./China LWAd = 6.40 B(A)
LWAd = 6.70
B(A)
Ready For U.S.A./China LWAd = 4.60 B(A)
Except for U.S.A./China LWAd = 4.54 B(A)
LWAd = 4.60
B(A)
Environment Temperature
Operating: 10 to 32.5°C
Storage: 0 to 40°C
Humidity Operating: 20 to 80 %
Storage: 10 to 90 %
Dimensions
(WxDxH)
Carton 475 x 454 x 331 mm (18.7 x 17.9 x 13.0 in.)
Printer 368 x 360 x 183 mm (14.5 x 14.2 x 7.2 in.)
Weights
without Carton,
with toner/drum
6.7kg / 14.8lb

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
