Brother HL-2250DN Service Manual

2-18
Confidential
3.4 Error indication at Service Calls
If LED indication does not operate when service calls occur, distinguish the type of error by
operating the Printer Settings printing or Maintenance printing. If you can not print, you can
use a Status Monitor to distinguish the type of error.
Error indication
(Printout of Printer Settings)
Error indication
(
Printing for Maintenance )
Status
code
Type of error
Refer
to:
ERROR S01 ERROR S01
40057 Main PCB failure 4.8.1
ERROR S02 ERROR S02
ERROR S03 ERROR S03
ERROR S04 ERROR S04
ERROR S05 ERROR S05
ERROR S06 ERROR S06
ERROR S07 ERROR S07
ERROR S08 ERROR S08
ERROR S09 ERROR S09
ERROR S10 ERROR S10
ERROR S11 ERROR S11
ERROR S12 ERROR S12
ERROR S13 ERROR S13
ERROR E49 FUSER MALF 2 50010
Fuser unit failure 4.6.1ERROR E50 FUSER MALF 50003
FUSER ERROR FUSER ERROR 50076
ERROR E51 LASER BD MALF 50004
Laser unit failure
(Laser beam detection error)
4.7.1
ERROR E52 SCANNER MALF 50005
Laser unit failure
(Scanner motor failure)
4.7.1
ERROR E54 MOTOR MALF 60004 Main motor failure 4.9.3
ERROR E55 HIGH VOL MALF 50000
High voltage power supply
PCB ASSY failure
4.8.4
ERROR E60 ERROR E60 50006
Fuser fan failure or Harness
connection failure of T1
clutch ASSY
4.9.2
ERROR H61 PROG ERROR 50001
Main PCB failure 4.8.1
ERROR H63 ERROR H63 50002
ERROR H66 NV-W ERROR
30035ERROR H67 NV-R ERROR
ERROR H68 NV-B ERROR
ERROR H75 ERROR H75 60030
Irregular power supply
detection error
4.8.5

Brother HL-2250DN Specifications

General

Color	No
N-up printing	2, 4, 6, 25
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	5 ppm
Maximum internal memory	- MB
Sound power level (standby)	31 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	100 sheets
Total number of input trays	1
Maximum duty cycle	- pages per month
Page description languages	PCL 6
Custom media width	76.2 - 216 mm
Maximum print size	216 x 406 mm
Custom media length	116 - 406.4 mm
Paper tray media types	Bond paper, Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Transparencies
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Sustainability certificates	ENERGY STAR
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	65 W
Power consumption (printing)	495 W
Power consumption (PowerSave)	0.9 W
Package weight	8300 g
Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	20 - 80 %
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Mac operating systems supported	Mac OS X 10.4 Tiger, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard
Server operating systems supported	Windows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64
Windows operating systems supported	Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64

Weight and Dimensions

Dimensions (WxDxH)	368 x 360 x 183 mm
