Brother HL-2270DW - Components

2-8
Confidential
2.5 Components
Fig. 2-4
Top cover ASSY
Top cover ASSY
Top cover base
Back cover
Outer chute
ASSY
Main PCB ASSY
Paper eject
sensor PCB ASSY
Panel PCB ASSY
Filter
Laser unit
Pinch rollers ASSY
Low voltage power
supply PCB ASSY
Fuser gear
28/34
Develop drive
sub ASSY
Fuser unit
Develop joint
Develop gear joint/52
Rubber foot
Fuser fan
Hight voltage power
supply PCB ASSY
Wireless LAN
PCB ASSY
Pick-up roller
holder ASSY
Paper tray
Front cover ASSY
Duplex tray
Side cover L
Side cover R
Inner chute ASSY
Fuser cover
Support flap 2
Support flap 2
Top cover ASSY
<HL-2130/2135W>
Top cover ASSY
<Except for HL-2130/2135W>
SW key
SW key
REG clutch
ASSY
T1 clutch ASSY
Conductive bushing 5
SW key holder
