Brother MFC-820CW - Page 141

Menu and Features
125
LAN
(Continued)
TCP/IP(WLAN)
(Continued)
Subnet Mask [000-255].
[000-255].
[000-255].
[000-255]
Enter the Subnet mask.
See
Network
User's
Guide
on the
CD-
ROM
Gateway [000-255].
[000-255].
[000-255].
[000-255]
Enter the Gateway
address.
Node Name BRW_XXXXXX Enter the Node name.
WINS Config Auto*
Static
Chooses the WINS
configuration mode.
WINS Server (Primary)
000.000.000.000
(Secondary)
000.000.000.000
Specifies the IP address of
the primary or secondary
server.
DNS Server
(Primary)
000.000.000.000
(Secondary)
000.000.000.000
Specifies the IP address of
the primary or secondary
server.
APIPA On*
Off
Automatically allocates the
IP address from the link-
local address range.
Setup WLAN Setup Wizard — You can configure your
print server.
SecureEasySetup — You can configure the
wireless network easily.
Level1 Level2 Level3 Options Descriptions Page
The factory settings are shown in Bold with an asterisk.
