Brother MFC-8810DW Service Manual

3-6
Confidential
Main motor ASSY Taptite cup S M3x8 SR 4 0.8±0.1(8±1)
Main motor cover Taptite bind B M3x10 2 0.5±0.1(5±1)
MP solenoid Taptite bind B M3x10 1 0.5±0.1(5±1)
Main PCB shield calking ASSY Taptite bind B M4x12 4 0.8±0.1(8±1)
Duplex solenoid Taptite bind B M3x10 1 0.5±0.1(5±1)
Bottom frame L Taptite bind B M4x12 3 0.8±0.1(8±1)
Base plate
Taptite bind B M4x12 4 0.8±0.1(8±1)
Screw pan (S/P washer)
M3x12DB
20.45±0.05(4.5±0.5)
High-voltage power supply PCB
ASSY
Taptite bind B M4x12 2 0.8±0.1(8±1)
T1 paper feed actuator holder
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
Main frame R Taptite bind B M4x12 5 0.8±0.1(8±1)
MP feed frame Taptite bind B M3x10 2 0.5±0.1(5±1)
MP paper empty sensor PCB
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
T2 tray cover Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 side cover L Taptite bind B M4x12 1 0.8±0.1(8±1)
T2 side cover R Taptite bind B M4x12 1 0.8±0.1(8±1)
T2 front cover ASSY Taptite cup S M3x8 SR 1 0.8±0.1(8±1)
Under bar (Two) Taptite bind B M4x12 4 0.8±0.1(8±1)
T2 frame R unit
Taptite cup S M3x8 SR 2 0.8±0.1(8±1)
Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 paper feed frame unit Taptite cup S M3x8 SR 3 0.8±0.1(8±1)
T2 front beam Taptite bind B M4x12 2 0.8±0.1(8±1)
T2 paper feed actuator holder
ASSY
Taptite bind B M3x10 1 0.5±0.1(5±1)
T2 back cover Taptite bind B M4x12 2 0.8±0.1(8±1)
*1 South Korean models are not equipped with the earth plate, taptite cup S M3x8 SR screw,
and tapttite bind B M4x12 screw.
Location of screw Screw type Q'ty
Tightening torque
N.m (kgf.cm)

Brother MFC-8810DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 1200 x 1200 dpi
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 50, 000 pages
Memory	128 MB
Fax Speed	33.6 kbps
Processor	400 MHz
Connectivity	USB, Ethernet, Wi-Fi Direct
Scanning Resolution	Up to 19200 x 19200 dpi (Interpolated)
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Maximum Paper Size	Legal (8.5" x 14")
Print Speed	Up to 40 ppm
