Brother MFC-8810DW Service Manual

3-26
Confidential
9.4 Fuser cover
(1) Push the two knobs on the fuser cover, and pull the fuser cover down in the direction of
the arrow.
(2) Remove the fuser cover from the bosses on the fuser unit, and remove the fuser cover
from the machine.
Fig. 3-19
Fuser cover
Knob
Fuser unit
Boss
Knob
Boss

Brother MFC-8810DW Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	Up to 1200 x 1200 dpi
Automatic Duplex Printing	Yes
ADF Capacity	50 sheets
Monthly Duty Cycle	Up to 50, 000 pages
Memory	128 MB
Fax Speed	33.6 kbps
Processor	400 MHz
Connectivity	USB, Ethernet, Wi-Fi Direct
Scanning Resolution	Up to 19200 x 19200 dpi (Interpolated)
Mobile Printing	Brother iPrint&Scan, AirPrint, Google Cloud Print
Maximum Paper Size	Legal (8.5" x 14")
Print Speed	Up to 40 ppm
