Brother MFC-9330CDW User Manual

88
Resetting the drum counter A
When you replace the drum unit with a new
one, you must reset the drum counter by
completing the following steps.
IMPORTANT
Do not reset the drum counter when you
only replace the toner cartridge.
a Press to interrupt the error.
b Press .
c Press All Settings.
d Swipe up or down, or press a or b to
display Machine Info..
e Press Machine Info..
f Press Parts Life.
g Touch the dial pad area to light up the
LEDs.
h Press # until the Touchscreen message
changes.
i Press the color of the drum unit you
replaced.
j Press Yes.
k Press .
Replacing the belt unit A
Order No. BU-220CL
A new belt unit can print approximately
50,000 Letter or A4 size single-sided pages.
Replace Belt A
When the Replace Belt message appears
on the Touchscreen, you must replace the
belt unit.
After replacement, reset the belt unit by
following the instructions included with the
new belt unit (see Resetting the belt unit
counter on page 91).
IMPORTANT
• DO NOT touch the surface of the belt unit.
If you touch it, it could degrade print
quality.
• Damage caused by incorrect handling of
the belt unit may void your warranty.
a Make sure the machine is turned on.
b Open the top cover until it locks in the
open position.

Brother MFC-9330CDW Specifications

Print Specifications

print speed black	up to 23 ppm
print speed color	up to 23 ppm
print resolution	up to 600 x 2400 dpi

Copy Specifications

copy speed black	up to 23 cpm
copy speed color	up to 23 cpm
copy resolution	600 x 600 dpi

Scan Specifications

scan resolution optical	1200 x 2400 dpi
scan resolution interpolated	19200 x 19200 dpi
document glass size	8.5” x 11.7”

Fax Specifications

fax modem speed	33.6k bps
fax page memory	up to 500 pages
speed dial locations	200

Paper Handling

auto document feeder capacity	up to 35 pages
paper size maximum	up to 8.5” x 14” (legal)
standard paper capacity	250 sheets

Power and Energy

deep sleep mode power consumption	<2W
automatic duplex printing	Yes
energy star qualified	Yes
