■ Error code A200
During document scanning, the first side document scanning position sensor detected that the
document length was 90 cm or more.
< User Check >
- Use documents equal to or smaller than A4 size.
- Remove the jammed paper.
■ Error code A300
Though a document was fed and conveyed by the specified distance or longer, the first side
document scanning position sensor did not detect the passing of the paper.
< User Check >
- Match the document guide with the document size.
- Remove the jammed paper.
Document Jam
Clear the scanner jam, then press the Stop Key.
Step Cause Remedy
1 First side document scanning
position actuator catching on
some position
Re-assemble the first side document
scanning position actuator.
2 First side document scanning
position sensor failure
Replace the first side document scanning
position sensor PCB.
3 Main PCB failure Replace the main PCB ASSY.
Document Jam
Clear the scanner jam, then press the Stop Key.
Step Cause Remedy
1 First side document scanning
position actuator catching on
some position
Re-assemble the first side document
scanning position actuator.
2 Connection failure of the first
side document scanning position
sensor PCB harness
Reconnect the first side document
scanning position sensor PCB harness.
3 First side document scanning
position sensor failure
Replace the first side document scanning
position sensor PCB.
4 Main PCB failure Replace the main PCB ASSY.
