3.2 Error Message
The error messages displayed on the LCD of the machine and their description are shown in
the table below.
Error Message
State
Error
Codes
Refer
to:
Upper line Middle line
Access
Denied
Function Locked.
In the case of PC-print,
authentication of print restricted
ID failed.
--- 4.14.1
Function Locked.
Job Deleted. Press
Stop[X].
--- 4.14.1
Access Error
Press Stop[X].Put
the device back in
and try again.
The device was removed during
data was being processed.
--- 4.14.2
Calibration Calibration failed.
Insufficient Toner
for Calibration.
Dot counter or develop roller
counter of color toner has
reached the upper limit during
color density adjustment
performed from the control panel.
9802 2-72
Calibration failed.
Press [Retry], and
try again.
Density patch measurement
ended unsuccessfully during
color density adjustment
performed from the control panel.
9803 2-73
Error occurred with the value
measured during density sensor
sensitivity calibration.
9804 2-73
Calibration failed.
Turn the power off
and then back on
again.
Error occurred with the value
measured during color density
adjustment performed from the
control panel.
9801 2-72
Cartridge
Error
Put the Toner
Cartridge back in.
The new toner sensor of the
toner cartridge (Black) could not
detect a new cartridge properly.
4F01 2-51
Put the Cyan #C
Toner Cartridge
back in.
The new toner sensor of the
toner cartridge (Cyan) could not
detect a new cartridge properly.
4F04 2-51
Put the Magenta #C
Toner Cartridge
back in.
The new toner sensor of the
toner cartridge (Magenta) could
not detect a new cartridge
properly.
4F03 2-51
Put the Yellow #C
Toner Cartridge
back in.
The new toner sensor of the
toner cartridge (Yellow) could not
detect a new cartridge
properly.
4F02 2-51
Condensation Leave switched
ON. Fully open the
Front Cover. Wait
30 minutes, switch
OFF and close
cover, then switch
ON.
Condensation occurred in the
machine.
1400 2-46
